Canon DZ3600u manual Adjusting the Focus of, To Adjust the Focus to a More Distant Setting, Mode

Adjusting the Focus of	Mode
	Preview
Preview Images

The focus is normally adjusted with the autofocus function, but it can be adjusted manually with the procedures below.

!!! Important !!!

•Do not forget to reset the DZ-3600U to autofocus (auto indicator on) after you have manually adjusted an image and are displaying the next.

•Pressing the [Auto] button in autofocus mode will turn off the autofocus. There will not be any noticeable change until another docu- ment or object is substituted and appears out of focus.

•••Note •••

•Use the manual focus when you wish to focus on different parts of a three- dimensional object. Please note that the focal range is approximately 65 mm or greater with the lens zoomed in.

•It may be difficult to focus on some objects - such as glossy items, translu- cent items, dark cloth and other items with a low reflection profile - with the autofocus. Use the manual focus for these objects.

•The focus can be adjusted manually even in still mode if the control panel is used. However, the change in focus cannot be verified unless a video monitor is directly connected to the DZ-3600U.

3

Procedure with the Remote Control

W	ZOOM
	T	LIGHTS
–BRIGHTNESS+		COLOR
	FOCUS
AUTO	NEAR	FAR
APP	REV	FWD

To Adjust the Focus to a More Distant Setting

Press the [Far] button.

•Autofocus will shut off when the button is pressed.

An Introduction to the Features

To Adjust the Focus to a Closer Setting

Press the [Near] button.

• Autofocus will shut off when the button is pressed.

To Turn Autofocus On/Off

Press the [Auto] button.

• Autofocus is turned on or off each time the button is pressed. 67
