OUTPut:EXTernal[1][:STATe]

Comments ∙ Executable when initiated: No

∙Coupled Command: No

∙Related Commands: OUTPut:EXTernal[1]:[:STATe]

∙*RST Condition: OUTPut:EXTernal:FEED “ TRIGger:STARt”

Example Setting the sync pulse source

OUTP:EXT:FEED “ROSC”

Output the reference oscillator pulses

:EXTernal[1][:STATe]

OUTPut:EXTernal[1][:STATe] <mode > enables or disables output of the synchronization pulse on the front panel "Ext 1" BNC.

Parameters

Parameter	Parameter	Range of	Default
Name	Type	Values	Units

mode	boolean	OFF0ON1	none

Comments ∙ Executable when initiated: No

∙Coupled Command: Yes, this command will cause a settings conflict error if the EXTernal1 BNC connector is already in use. The following commands can use the EXTernal1 connector: ARM:STARt:SOURce1 or ARM:STARt:SOURce2

∙*RST Condition: OUTPut:EXTernal[1][:STATe] OFF

Example Enabling sync pulse output to the front panel "Ext 1" BNC

OUTP:EXT ON

Enable sync pulse output on "Ext 1" BNC

:TTLTrg<n>:FEED

OUTPut:TTLTrg<n>:FEED<source > selects which event will cause a pulse or level change on the TTL trigger line(s). Note that unlike the ECL trigger lines, there is only a single FEED that goes to all TTL trigger lines. Therefore, it does not matter what value of <n> is specified with this command, because all TTL trigger lines share the same feed. The available feed sources are:

246 Command Reference

OUTPut Subsystem

Image 246
