Section 4 - Chapter 3 - TCP/IP Configuration and Printing
Example: The following example prints a PostScript file called chart.ps to the OkiLAN 6120e printer Port 1 using FTP.
$ ftp OkiLAN 6120e_name<Enter> Connected to OkiLAN 6120e_name.
220
Name (OkiLAN 6120e_name:anyone):<Enter> 230 User logged in.
ftp> binary<Enter> 200 Type set to I.
ftp> put chart.ps MPX1<Enter> local: chart.ps remote: MPX1
200 PORT command successful.
150 Opening BINARY mode data connection for MPX1.
226 Transfer complete.
4549 bytes sent in 0 seconds (4.4 Kbytes/s) ftp> bye<Enter>
221Goodbye.<Enter>
$
Timeout Checking
If timeout checking is enabled on the OkiLAN 6120e, the OkiLAN 6120e will close any connection that stays idle for more than five minutes. For example, if you open an FTP connection to the OkiLAN 6120e and walk away from your computer for more than five minutes, the FTP connection will be closed. You can reestablish a connection to the OkiLAN 6120e with the OPEN command.
TCP/IP
OKI OkiLAN 6120e User’s Guide | IV - 21 |
