Returning a Hard Drive to Dell | Dell PP01L guide

NOTICE: Use firm and even pressure to slide the hard drive into place. If you force the drive into place using excessive force, you may damage the connector.

8Push the hard drive into the hard drive bay until the drive is fully seated.

9Replace and tighten the screw(s) you removed in step 4.

10Use the Operating System CD to install the operating system you are using for your computer (see page 68).

11Use the Drivers and Utilities CD to install the drivers and utilities for your computer (see page 58).

Returning a Hard Drive to Dell

Return your old hard drive to Dell in its original or comparable foam packaging. Otherwise, the hard drive may be damaged in transit.

hard drive

Re placing Par ts

89

Image 89

Dell PP01L manual Returning a Hard Drive to Dell, Hard drive Re placing Par ts
