Battery (continued)

Life span (approximate)	500 discharge/charge cycles
Temperature range:
Operating	0° to 35°C (32° to 95°F)
Storage	–40°to 65°C (–40°to 149°F)

AC Adapter

Input voltage	90 to 264 VAC
Input current (maximum)	1.7 A
Input frequency	47 to 63 Hz
Output current	4.5 A (maximum at 4-second pulse);
	3.5 A (continuous)
Output power	70 W
Rated output voltage	19.5 VDC
Dimensions:
Height	27.94 mm (1.1 inches)
Width	58.42 mm (2.3 inches)
Depth	133.85 mm (5.25 inches)
Weight (with cables)	0.4 kg (0.9 lb)
Temperature range:
Operating	0° to 35°C (32° to 95°F)
Storage	–40°to 65°C (–40°to 149°F)

Physical

Height	36.8 mm (1.4 inches)
Width	319.5 mm (12.5 inches)
Depth	253.6 mm (9.9 inches)

A ppe ndix

99
