Table 7-2. System Board Connectors

Item

Connector

Description







1

CPU2

Processor 2







2

iDRAC6 Enterprise

iDRAC 6 Enterprise card connector







3

B4

Memory module slot B4



B1

Memory module slot B1 (white release lever)



B2

Memory module slot B2 (white release lever)



B3

Memory module slot B3 (white release lever)







4

CPU1

Processor 1







5

FAN1

System fan 1 connector







6

FAN2

System fan 2 connector







7

A3

Memory module slot A3 (white release lever)



A2

Memory module slot A2 (white release lever)



A1

Memory module slot A1 (white release lever)



A4

Memory module slot A4







8

FAN3

System fan 3 connector







9

FAN4

System fan 4 connector







10

12V

8-pin power connector







11

FP_CONN

Control panel connector







12

BP_CONN

Backplane power connector







13

PWR_CONN

24-pin power connector







14

PDB_ I2C

Power distribution board connector







15

FP_USB_CONN

Control panel USB connector

NOTE: For the full name of an abbreviation or acronym used in this table, see the "Glossary" on page 175.

Jumpers and Connectors

171
