Option

Description





Logical Processor

On processors that support Simultaneous Multi-

(Enabled default)

Threading (SMT) technology, each processor core



supports up to two logical processors. If this field is set to



Enabled, the BIOS reports both logical processors. If set



to Disabled, only one logical processor is monitored by



the BIOS.





Virtualization Technology

NOTE: Disable this feature if your system will not be

(Disabled default)

running virtualization software.



Enabled permits virtualization software to use the



virtualization technology incorporated in the processor.





Execute Disable

Enables or disables Execute Disable Memory Protection

(Enabled default)

Technology.





Number of Cores per

If set to All, the maximum number of cores in each

Processor

processor is enabled.

(All default)







Turbo Mode

If Turbo Boost Technology is supported by the

(Enabled default)

processor(s), enables or disables Turbo Mode.





C States

When set to Enabled, the processor(s) can operate in all

(Enabled default)

available power states.





Processor 1 Family -Model-

Displays the family, model, and stepping of the selected

Stepping

processor.





SATA Settings Screen

Option

Description





Embedded SATA

ATA Mode enables the integrated SATA controller. Off

(ATA Mode default)

disables the controller.





Port A

Auto enables BIOS support for the device attached to

(Auto default)

SATA port A. Off disables BIOS support for the device.





Port B

Auto enables BIOS support for the device attached to

(Off default)

SATA port B. Off disables BIOS support for the device.





Port C

Auto enables BIOS support for the device attached to

(Off default)

SATA port C. Off disables BIOS support for the device.

62

Using the System Setup Program and UEFI Boot Manager
