Wiring and Connections | Section | |
|
|
|
3-4-5 Output Wiring
Relay Output Wiring
Wire the outputs to the CPM1A’s CPU Unit and Expansion I/O Unit as shown in the following diagrams. Use crimp connectors or solid wire (not stranded wire) to connect to the PC. The power supply output terminals can be used with
•Always use solid wire or attach crimp connectors if a stranded wire is used.
•Do not connect loads or apply voltages exceeding the maximum switching ca- pacity to the output terminals.
•Don’t exceed the output capacity or the maximum common current. Refer to
•Each common terminal is separated from one another for each group of output terminals.
Item | Specification |
|
|
Output capacity | 2 A (250 VAC or 24 VDC) |
|
|
Max. common capacity | 4 A/common |
!WARNING The PC outputs may remain ON or OFF due to deposition or burning of the output relays or destruction of the output transistors. External safety measures must be provided to ensure safety in the system. Not providing proper safety measures may result in serious accidents.
52
