Page 114

Programming Example	Section 4-4

3.Clear the CPM1A’s memory by pressing the CLR, SET, NOT, RESET, and then the MONTR Key. Press the CLR Key several times if memory errors are displayed.

00000

CLR

SET NOT RESET

00000MEMORY CLR?

HR CNT DM

00000MEMORY CLR

MONTR END HR CNT DM

4.Display and clear error messages by pressing the CLR, FUN, and then the MONTR Key. Continue pressing the MONTR Key until all error messages have been cleared.

00000

CLR

00000

FUN FUN (0??)

ERR/MSG CHK OK

MONTR

5.Press the CLR Key to bring up the initial programming display (program address 00000). The new program can be written at this point.

00000

CLR

!Caution Check the system thoroughly before starting or stopping the CPM1A to prevent any accidents that might occur when the program is first started.

102
