Tftp Commands, Using copy-TFTP command

Appendix B: Redirection Server

Usage

event-level <NUM> output-device <Logging media>

Parameter(s)

<NUM>

It is the event level number. It is a number between 0-1000 Initial value 0.

The media to use for logging, console: sys-Logger none, Initial value none

Example:

RDSHost> configure terminal <cr>

RDSHost(config)# Event-level 1 output-device log-file

TFTP COMMANDS

Using copy-TFTP command

•The copy-TFTP command enables the upgrading of new RDS software.

•The new upgraded software is affecting after reloading the system.

•It is located at the “main” menu.

•It upgrades only standard RDS pack files.

•Download process reports the following errors:

a.Download timeout b.File not found

c. Download hardware problem d.Download pack file is corrupted

Usage

copy-TFTP flash <IP address> <File name>

Parameter(s): <IP address>

This is the IP address of the TFTP server.

This is the file name to download. Valid name: 1 to 255 alphanumeric characters.
