Problem solving
Resolving an interposer problem
| Table | ||
|
|
|
|
Problem |
| Suggested solutions |
|
|
|
|
|
Repeated jams in |
| Follow the jam clearance diagram in the Printer Fault Clearance window |
|
interposer |
| carefully to ensure all paper has been cleared. |
|
|
| Make sure the stock in trays 4 and 5 have been loaded correctly. Refer to |
|
|
| the Satisfaction guides in chapter 4, “Technical Information”, for information |
|
|
| on loading stock in trays 4 and 5. |
|
|
| Make sure the stock in trays 4 and 5 meet the specifications for these trays |
|
|
| as indicated in the Satisfaction guides in chapter 4, “Technical Information”. |
|
|
|
|
|
Resolving a finisher problem
| Table | |
|
| |
Problem | Suggested solutions | |
|
| |
Repeated jams in area | The bindexer contains three bins used by the system to sort sets. The | |
14 (bindexer) | capacity of each bin is 125 sheets of substance 20 (75 g/m2) or 0.5 inch | |
| (13 mm) thickness. | |
| Include inserts and covers when considering the output capacity of the | |
| bindexer. | |
| 125 sheets of substance 20 (75 g/m2) is equal to approximately: | |
| 104 sheets of substance 24 (90 g/m2) | |
| 78 sheets of substance 32 (120 g/m2) | |
| 47 sheets of substance 110 (200 g/m2). | |
| Check that the sets in the bindexer are less than 0.5 inch (13 mm) thick. | |
| If the set exceeds 0.5 inch (13 mm) thickness, reprogram the job for fewer | |
| sheets or reduce the number of | |
| When running collated, unfinished sets, the maximum sheet capacity of the | |
| bindexer can be set between 50 and 125. | |
| When running anything other than collated, unfinished sets, the maximum | |
| sheet capacity of the bindexer will remain at 125. | |
|
| |
Jammed binder tape, | Replace the tape reel with a new reel using the procedure, "Replacing the | |
such as binder tape | binder tape reel," in this guide. | |
sticking together, or | Refer to the binder tape reel storage information in this guide. | |
cosmetic defects in | ||
| ||
the bound book |
| |
|
| |
Binder tape not | Adjust the binder tape registration using the procedure, "Adjusting the | |
positioned correctly on | binder tape registration," in this guide. | |
the top edge of the |
| |
output prints |
| |
|
|
