Problem solving
Figure 6-5. Removing the wire fragments
c.Remove the copy paper carefully, being sure not to drop any wire fragments into the system.
10.Push the green stitcher head release handle down and back.
11.Pull the plug from the measuring bracket.
12.Insert the plug into the stitcher head until the plug snaps into place.
NOTE: Ensure that the wire cutters are not touching the stitcher spools. This can prevent the stitcher wire from feeding properly.
13.Place the wire cutters in the storage bracket.
NOTE: Ensure that the stitcher panel has been lowered. The stacker will not deliver printed sets if the stitcher panel is left in the up position.
14.Lower the stitcher panel.
15.Close the finisher doors. The printer icon indicates "Ready."
