Appendix A: Configuration

Event

Meaning





The UBA application connects to the database.

This event causes a message similar to the following to



display:



DB_CONNECT Connecting to <sid> as



<user>



If you see this database connection message without prior



errors, the UBA application has passed the syntax check.





15.Ensure that the Bulk input files can be read.

To verify that the UBA application can read the Bulk input files, follow these steps:

15-a. Place a Bulk input file at the source input location.

(443 only) The source input location for Bulk input files is specified using the URI parameter from the pack’s XSD file, which you can view using the Topology Editor.

(Pre-443 only) The source input location for Bulk input files is specified using the URI parameter from the template file, which you added to the dc.cfg file in a previous step.

Within the configured file retrieval interval (typically, five minutes), the UBA application retrieves the Bulk input file and copies it to the following directory:

DATA_CHANNEL_HOME/UBA.<channel>.<collector>/<instance>/do/

where:

Variable

Meaning

DATA_CHANNEL_HOME

Is /opt/datachannel, by default.





<channel>

Specifies the channel number (for example, 1) you



specified when configuring this DataChannel.





<collector>

Specifies the collector number (for example, 100) you



specified when configuring this UBA Bulk Collector.





<instance> (443 only)

Specifies the string for the INSTANCES parameter in the



pack’s XSD file. Typically, this string represents the name



of the pack and is read-only. You can view the string



specified for INSTANCES using the Topology Editor.





<instance> (pre-443 only)

Specifies the string for the INSTANCES parameter in the



pack’s template file. You were instructed to copy this



parameter to the dc.cfg file in a previous step.

The UBA application then processes the Bulk input file according to the instructions in the Bulk Adaptor Design File.

Note: The first time that the UBA processes a Bulk input file, it passes a metric to the CME. The CME rejects this metric as a BAD_METRIC because the metric does not have an associated grouped sub-element prior to the time this metric is recorded. This is expected behavior. The CME accepts metrics from the Bulk input files after the inventory is run.

15-b. Ensure that the UBA application can successfully read the Bulk input file you copied into the source input location by issuing a tail utility command similar to the following:

452

Netcool/Proviso Cisco IP Telephony Technology Pack User’s Guide, Version 4.3-W
