Syntax

cfggen <controller #> delete [noprompt]

Parameters



<controller #>

A SAS controller number between 0 and 255.

[noprompt]

Eliminates warnings and prompts.

Operation

After entering the DELETE command, the system prompts you and asks if you want to proceed with the command. Enter Yes if you want to proceed.

DISPLAY

This DISPLAY command displays information about controller configurations: controller type, firmware version, BIOS version, volume information, and physical drive information.

Syntax

cfggen <controller #> display [filename]

Parameters

<controller #>

A SAS controller number between 0 and 255.

[filename]

Valid filename to store output of command to a file.

Sample Output

Read configuration has been initiated for controller 0

------------------------------------------------------------------------

Controller information

------------------------------------------------------------------------

Controller type

: SAS1068

EFI BSD version

: 2.00.09.00

Firmware version

: 1.10.01.00

Channel description

: 1 Serial Attached SCSI

Initiator ID

: 63

Maximum physical devices

: 62

Concurrent commands supported

: 511

------------------------------------------------------------------------

IR Volume information

------------------------------------------------------------------------

IR volume 1



Volume ID

: 2

Status of volume

: Okay (OKY)

RAID level

: 1

Size (in MB)

: 34304

Physical hard disks (Target ID)

: 9 1

------------------------------------------------------------------------

Physical device information

------------------------------------------------------------------------

Initiator at ID #63



Target on ID #1



Device is a Hard disk



Enclosure #

: 1

Slot #

: 8

Target ID

: 1

State

: Online (ONL)

Size (in MB)/(in sectors)

: 34732/71132960

Manufacturer

: HP

Model Number

: DG036A8B53

Firmware Revision

: HPD6

Serial No

: 3LC04757000085425VFK

Drive Type

: SAS

Target on ID #4



302 Core I/O Card Utilities
