Setup Menus

Default Language, Character Set & Codepage Settings

Language	KBDTYPE	CHARSET	SBCS	DBCS
Language	KBDTYPE	CHARSET	CODEPAGE	CODEPAGE
English (US)	USB	697	37

English (UK)	UKB	697	285

Belgian	BLI	697	500

Canadian French	CAI	697	500

Danish	DMB	697	277
Finnish	FNB	697	278

German	AGB	697	273

Dutch	NEB	697	37

Italian	ITB	697	280

Swiss French	SFI	697	500

Swiss German	SGI	697	500

Swedish	SWB	697	278
Norwegian	NWB	697	277
French	FAB	697	297
Spanish	SPB	697	284

Portuguese	PRB	697	37

Japanese Kanji + Katakana	JKB	1172	290	300

Korean	KOB	1173	833	834

Simplified Chinese	RCB	1174	836	837
Traditional Chinese	TAB	1175	37	835
Hebrew New Code	NCB	941	424
Hebrew Old Code		941	803
Thai	THB	1176	838

Greek	GNB	925	875
Cyrillic	CYB	960	880
Turkish	TRB	1152	1026
Russian	RUB	1150	1025
Czech	CSB	959	870
Slovak	SKB	959	870
Polish	POB	959	870
Icelandic	ICB	697	871
Arabic		697	420

5-48
