IBM 3151 Emulation

KEYS LOCKED appears when the keyboard is locked. The keys will be unlocked when the Keyboard Unlock command is received or when the Cancel key is pressed.

NUMERIC indicates the cursor is located in an unprotected numeric field.

PRINTING indicates that data is being sent to the printer.

SENDING indicates that data is being sent to the host.

WRONG PLACE appears when you press an invalid key in a protected field or field attribute character position. It is also displayed when you try to insert a character or line in a screen already full when the Forcing Insert option is set to Off.

If two or more messages are sent to a particular field, then the message with the highest priority will be displayed. Messages in field 4 are displayed in the following order:

HOLD SCREEN

SENDING

PRINTING

KEYS LOCKED

INVALID KEY

WRONG PLACE

NUMERIC

Keyboard Mapping

The following illustration shows where IBM 3151 keyboard functions are mapped to keys on the 101/102 key Enhanced AT keyboard layout. Special key functions can be mapped to any key on your keyboard by using the virtual key names listed in the Define Keyboard Macros dialog box.

11-4
