DG 410/412 Emulation

7

DG 410/412 Emulation

This chapter describes the Data General D410/412 terminal emulation.

Session Configuration

WBT Mode

This section describes the basic procedure for creating a session configuration when the terminal is in WBT mode. The options available are described in detail in chapter 2.

1.Click the Configure tab in the Terminal Connection Manager then click the Add button to display the New Connection dialog box.

2.Select Terminal Emulation Client and click OK. The Terminal Emulation Client Connection Wizard - Connection Information dialog box will be displayed.

3.Enter a name which will identify this session configuration for future selection in the Connection Name box.

4.Select the DG 410/412 terminal emulation in the Emulation list box. This emulation provides compatibility with software designed to drive the Data General D410/412 terminal.

5.Click Next to display the Host Information dialog box.

For a TCP/IP connection, click the TCP/IP button, enter the name or internet address of the host computer in the Host Name box, then click Advanced for additional Telnet options. Refer to the TCP/IP Connection Settings section in chapter 2 for details.

For a modem connection, click the Modem button then click Advanced to display configuration options. Refer to the Modem Connection Settings section in chapter 2 for details.

7-1
