Setup Menus

The following 'backslash' values can be used:

\u

Unicode introducer

\r

Carriage return

\n

Line feed

\e

Escape

Note that as the \ and ^ characters are used as value introducers, to enter these as character values you need to precede them with a backslash character, i.e. enter \ as \\ and ^ as \^.

The Euro character can be specified by entering the unicode value \u20ac.

Creating A Connection Template

You can save the current session configuration as a connection template. To make the emulator automatically attempt to make a host connection using the same settings the next time it is loaded, display the File menu and select the Save Session option.

You can create multiple connection templates when the terminal is not in WBT mode, any one of which can be selected for use. The procedure is as follows:

1.In the File menu, select the Save Session As... option to display the following dialog box.

2.In the Saved Items box, indicate which settings are to be saved by checking the boxes next to the relevant options.

3.In the Save As File Name text box, enter a descriptive name to enable it to be identified for future selection. This description will be listed in the Open Session dialog box.

4.Click the OK button to save the template settings. If you specified a descriptive name that already exists, a message box will ask you to confirm whether or not you want to overwrite the existing name with the new settings.

5-5
