CAUTION: Do not pull on the cable to unseat the connector. Doing so can damage the cable.

Figure 3-33. Removing and Installing the Front-Panel IO Module (Twelve–Hard-Drive System)

1

2

3

4

1	front-panel IO cable	2	bracket
3	front-panel IO module	4	mounting screws (3)

Installing System Components

155
