Figure 3-30. Removing and Installing the Control Panel—LED (Four–Hard-Drive System)
| 1 |
| 8 |
| 2 |
7 | 3 |
|
| 6 |
|
|
|
|
| 4 |
|
| 5 |
|
1 | control panel cable | 2 | USB memory key connector |
3 | power cable | 4 | standoff |
5 | LED display module | 6 | slot |
7 | control panel board | 8 | mounting screws (2) |
