3.4EMAC Control Module Interrupt Control Register (CMINTCTRL)

www.ti.com

EMAC Control Module Registers

3.4EMAC Control Module Interrupt Control Register (CMINTCTRL)

The interrupt control register (CMINTCTRL) is shown in Figure 16 and described in Table 13.

Figure 16. EMAC Control Module Interrupt Control Register (CMINTCTRL)

31	30		18	17	16
Reserved		Reserved		INTPACEEN
R/W-0		R-0			R/W-0
15	12	11			0
	Reserved		INTPRESCALE
	R-0		R/W-0
LEGEND: R/W = Read/Write; R = Read only; -n= value after reset

		Table 13. EMAC Control Module Interrupt Control Register (CMINTCTRL)
			Field Descriptions
Bit	Field	Value	Description
31	Reserved	0	Reserved
30-18	Reserved	0	Reserved
17-16	INTPACEEN	0-3h	Interrupt pacing enable.
			Bit 16 = 1; enables Rx_Pulse Pacing; = 0, disables pacing
			Bit 17 = 1; enables Tx_Pulse Pacing; = 0, disables pacing
15-12	Reserved	0	Reserved
11-0	INTPRESCALE	0-7FFh	Interrupt counter prescaler. The number of peripheral clock periods in 4 μs.

SPRUEQ6–December 2007	Ethernet Media Access Controller (EMAC)/Management Data Input/Output (MDIO)	63
