Setting Hard Disk ID Options

Strapping the SCSI IDs on the Drive

You can use connector J1-A (see Figure D-7) to configure the SCSI IDs. See the table below.

Table D-3. SCSI Drive ID Settings

SCSI ID

Bit3

Bit 2

Bit 1

Bit 0











0

0

0

0

0

1

0

0

0

1

2

0

0

1

0

3

0

0

1

1

4

0

1

0

0

5

0

1

0

1

6

0

1

1

0

7*

0

1

1

1

8

1

0

0

0

9

1

0

0

1

10

1

0

1

0

11

1

0

1

1

12

1

1

0

0

13

1

1

0

1

14

1

1

1

0

15

1

1

1

1

0=Jumper shunt not installed 1=Jumper shunt installed

*SCSI ID7 reserved for SCSI controller board

NCR S26 Hot Plug Server User Guide

D-13

Page 153
