You should install the online help when you receive a new version of the analyzer software, or if you are setting up the analyzer to use on a networked system (see “To Connect the Analyzer as a Networked System” on page 1-10).

To Install the Online Help on a PC

You can install the analyzer online help on any PC with Windows 3.1 or higher.

1Insert the Help for Windows diskette 1 (p/n E5200-10017) in drive A. If you have a CD-ROM drive attached to the notebook PC, use the supplied CD-ROM.

2From the File menu, select Run.

3Type a:\setup to install the help ﬁles from the diskettes. Type d:\help\win\setup to install the help ﬁles from the CD-ROM.

4Click OK.

Follow the instructions on the screen. After you restart Windows, three help icons (one for each help volume), and a readme ﬁle icon appear in the HP Broadband Analyzer program group.
