Windows NT4.0 - Installing the IPDL-C Printer Driver

J Select the name of the printer whose driver you want to install by clicking it, and then click [Next].

A dialog for changing the printer name appears.

K Change the name of the printer if you want, and then click [Next].

L If the printer is to be shared over a network, click [Shared] to select it.

Selecting [Shared] causes the computer you are on to operate as the printer server. If you select [Not shared] here, skip step M.

M In the [Shared Name] box, type in the name that printer should use on the net-

work.



The initial default Shared name is the same name as the Name box in step K,



above. You can leave this name as it is, or change to a different one.



4

N Click [Next].



O Specify whether or not you want to print a test page, and then click [Finish].



The printer driver files are copied from the CD-ROM to your computer's hard disk.

After installation is complete, the [Printers] window appears with the icon of the newly installed printer.

P Restart Windows.

Q After Windows restarts, set up any options you have installed on the print- er.

Reference

P.41 “Setting Up Options”

Setting Up Options

A Click [Start], point to [Settings], and then click [Printers].

The [Printers] window appears.

B Select the icon of the printer you want to use by clicking it. On the [File] menu, click [Properties] .

C Click the [Installable Options] tab.

D Use the [Option Tray] listbox to specify the optional tray unit.

Specifying the wrong tray here will make it impossible to use your tray cor- rectly.

41
