Accessing the system boards
This section discusses the procedures in:
•Removing and installing the access cover to the system boards
•Removing and installing the memory board
•Removing and installing the processor board
•Removing and installing the mainboard
Caution! A microprocessor and heat sink may be hot if the system has been running. Also, there may be sharp pins and edges on some board and chassis parts. Contact should be made with care. Consider wearing protective gloves.
Access cover to the system boards
To remove the access cover to the system boards
1Remove the rear access panel (refer to page 44).
2Loosen the two captive screws located at the front of the access cover to the system boards.
3Lift the end of the cover where the screws are located and remove the cover.
