130 | Acer G901 instruction

130	4 BIOS setup

Parameter	Description	Option

Serial Port A/B	Base address and IRQ (interrupt request)
Base I/O Address	setting for serial port A/B. Options
Interrupt	include:
	Enabled - user assigned configuration
	Disabled - no configuration
	Auto - configuration is assigned by BIOS
	or the system operating system

Auto

Disabled

Enabled

Parallel Port

Mode

Base I/O Address

Interrupt

DMA Channel

Mode, base address, IRQ, and DMA channel for the parallel port.

Mode - sets the operation mode

Base address - sets a logical base address

Interrupt - sets the IRQ

Auto

Disabled

Enabled

DMA Channel - assigns a DMA (Direct Memory Access) channel for the ECP (Extended Capabilities Port) parallel port function. This parameter is configurable only if the operation mode is ECP.

Legacy USB	Enable this parameter when you intend
Support	to use a USB device and are using a
	non-Plug and Play operating system, such
	as DOS.

Disabled

Enabled

PS/2 Mouse	Enable this parameter if you intend to	Disabled
	use a mouse or trackball with a PS/2	Enabled
	interface.
