VR800 Owner’s Manual (Saving and Loading Song Data)
<Memo>
If Program data to be saved is larger than the space available on one backup disk, the VR800 tells you how many backup disks you need when you select a Program in Step 6 of the previous procedure.
DIGITAL44.1kHz
SYNC OUT |
| DRIVE |
CLK | SCSI | |
|
|
|
AUTO |
| A.PUNCH |
(e.g.)
Two backup disks are required.
DIGITAL44.1kHz
SYNC OUT |
| DRIVE |
CLK | SCSI | |
|
|
|
AUTO |
| A.PUNCH |
(e.g.)
Three backup disks are required.
When you set the first disk, the save operation starts. When the disk is full, the VR800 automatically ejects the disk and displays [Ins. Disk 2] (meaning “Please set the second disk.”).
Set the second disk to continue the save operation.
Note: Mark the disks so that you can identify the order of the disks and you will be able to insert the disks in
the correct order to perform the load operation.
Loading data
*You can load data using the “Load PGM ?” menu in SETUP mode. The following procedure assumes that the backup disk has been inserted into the backup SCSI drive, and a formatted disk has been inserted into the current drive.
<[Load PGM ?] menu>
* Input signal options: [AdAt], [dAT], [SCSi
* Program options: | P01 - P99 (an individual Program) |
* Track options: | When using an adat or DAT: tracks |
| tracks |
| When using a SCSI disk: All tracks will be |
| automatically selected. |
1.Press the SETUP key to enter SETUP mode, then use the JOG dial to select [Load PGM ?] menu.
2.Press the EXECUTE/YES key.
[Device ?] appears, and the selected input signal option flashes. ([SCSi
|
|
|
|
| DIGITAL |
| 44.1kHz | Flashing | |||
|
|
|
|
|
|
|
|
| |||
|
|
|
|
|
| SETUP |
|
| |||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| SYNC OUT |
|
| DRIVE |
|
| |
|
|
|
|
| CLK | SCSI |
| ||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| AUTO |
|
| A.PUNCH |
|
| |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
DIGITAL44.1kHz
SETUP
Flashing
SYNC OUT |
| DRIVE |
CLK | SCSI | |
|
|
|
AUTO |
| A.PUNCH |
Normally, the initially displayed load device is the flash- ing [SCSi
[dAT] or [AdAt] is selected when DAT or adat is used for loading.
4. Select a flashing [SCSi id-6] and press the
EXECUTE/YES key.
The saved backup number (01) flashes. This means that B01 on the backup disk is selected to load.
If only this backup file exists on the disk, turning the JOG dial will allow you to select [B01] or [Eject].
Select [Eject] if you wish to change the disk.
If there are multiple backup files on the disk, using the JOG dial allows you to select the desired backup data (B01, B02, B03, etc.) or [Eject].
Flashing | DIGITAL | 44.1kHz |
|
| |
|
| MB |
| SYNC OUT | DRIVE |
| CLK | SCSI |
| AUTO | A.PUNCH |
5. Press the EXECUTE/YES key.
The VR800 indicates that the load destination disk (cur- rent drive disk) does not have any data, then indicates a flashing [SURE?].
At this time, using the JOG dial allows you to select the load destination Program.
DIGITAL44.1kHz
SETUP
MB
SURE ? |
|
|
|
|
| Flashing | |
| SYNC OUT |
| DRIVE |
| |||
| CLK | SCSI | |||||
|
|
|
|
| |||
| AUTO |
| A.PUNCH |
| |||
80
