Configuring the Driver

In Windows, Solaris LPFC, Solaris emlxs (SFS) and Linux: Set driver parameters using the HBAnyware utility. In Solaris LPFC, Solaris emlxs (SFS) and Linux:, you can also specify parameters when loading the driver manually. See the appropriate driver manual for instructions.

Setting Driver Parameters

The Driver Parameters tab and host Driver Parameter tab enable you to modify driver parameters for a specific HBA or all HBAs in a host.

For example, if you select a host in the discovery-tree, you can globally change the parameters for all HBAs in that host. If you select an HBA in the discovery-tree, you can change the lpfc_use_adisc, lpfc_log_verbose and the lpfc_nodev_tmo parameters for only that HBA.

For each parameter, the Driver Parameters tab and host Driver Parameters tab shows the current value, the range of acceptable values, the default value, and the activation requirement. You can also restore parameters to their default settings.

You can apply driver parameters for one HBA to other HBAs in the system using the Driver Parameters tab, thereby simplifying multiple HBA configuration. See “Creating and Assigning a Batch Mode Driver Parameters File” on page 52 for more information.

Note: The Linux 2.6 kernel only supports setting the log_verbose, nodev_tmo and use_adisk driver parameters for individual HBAs. You must apply other driver parameters to all HBAs contained in the host.

To change the driver parameters for a single HBA:

1.Do one of the following:

•From the menu bar, click View, then click Sort by Host Name.

•From the toolbar, click the Sort by Host Name button:.

2.In the discovery-tree, select the HBA.

The HBAnyware Utility User Manual Page 48
