8.The two radio buttons allow you to choose the type of parameters to save. You can save all parameters or only those parameters whose current values differ from their corresponding default values.
A list of the saved parameters and their current values show in the Saved Parameters box.
9.Click Save.
10.Assign batch mode parameters to HBAs: From the Batch menu select Update Driver Parameters. (You do not need to select any
11.Select the file whose parameters you wish to apply and click Open. The Batch Driver Parameter Update dialog box shows all the batch file compatible HBAs with a check mark beside them.
Figure 37: Batch Driver Parameters Update dialog box for Windows
Note: Solaris LPFC, Solaris emlxs (SFS) and Linux: A Browse button is included on the Batch Driver Parameters Update dialog box. The Browse button allows you to navigate to a different file.
12.Click Start. The HBAnyware Batch Driver Update dialog box shows the current status of the update. When the update completes, a final summary shows the number of HBAs that were successfully processed, and the number of HBAs for which one or more parameter updates failed.
13.If you wish, click Print Log to print a report of the update.
Note: Printing is not supported in Linux.
The HBAnyware Utility User Manual | Page 53 |
