Table 9: lpfc Static Parameters (Requires a driver reload to change) (Continued)
|
|
|
|
| Visible |
Variable | Default | Min | Max | Comments | using |
|
|
|
|
| sysfs |
|
|
|
|
|
|
|
|
|
|
|
|
lpfc_discovery_threads | 32 | 1 | 64 | Specifies the maximum | No |
|
|
|
| number of ELS commands |
|
|
|
|
| that can be outstanding for |
|
|
|
|
| a discovery. |
|
|
|
|
| NOTE: The |
|
|
|
|
| discovery_threads |
|
|
|
|
| parameter will default to a |
|
|
|
|
| value of 64 for private loop |
|
|
|
|
| topologies regardless of the |
|
|
|
|
| configured value. If there |
|
|
|
|
| are multiple ports |
|
|
|
|
| configured on the host the |
|
|
|
|
| value of 64 will only be |
|
|
|
|
| used for those ports that |
|
|
|
|
| are connected in a private |
|
|
|
|
| loop topology. The |
|
|
|
|
| configured value will be |
|
|
|
|
| used for all other ports. |
|
|
|
|
|
|
|
lpfc_enable_npiv | 0 | 0 | 1 | This parameter controls the | Yes |
|
|
|
| driver’s ability to use NPIV |
|
|
|
|
| to create virtual ports. It |
|
|
|
|
| defaults to off (0) which |
|
|
|
|
| prevents the driver from |
|
|
|
|
| creating any virtual ports. |
|
|
|
|
| When enabled (set to 1) it |
|
|
|
|
| enables you to create and |
|
|
|
|
| delete virtual ports (if |
|
|
|
|
| supported by the fabric). |
|
|
|
|
|
|
|
lpfc_fcp_class | 3 | 2 | 3 | The Fibre Channel class for | Yes |
|
|
|
| FCP data transmission. |
|
|
|
|
|
|
|
lpfc_hba_queue_depth | 8192 | 32 | 8192 | The maximum number of | Yes |
|
|
|
| FCP commands that can |
|
|
|
|
| queue to an Emulex HBA. |
|
|
|
|
|
|
|
lpfc_lun_queue_depth | 30 | 1 | 128 | The default maximum | Yes |
|
|
|
| commands sent to a single |
|
|
|
|
| logical unit (disk). |
|
|
|
|
|
|
|
lpfc_fdmi_on | 0 | 0 | 2 | False (0) if disabled. (1) or | Yes |
|
|
|
| (2) if enabled depending on |
|
|
|
|
| type of support needed. |
|
|
|
|
|
|
|
lpfc_scan_down | 1 | 0=Off | 1=On | Selects method for | Yes |
|
|
|
| scanning ALPA to assign a |
|
|
|
|
| SCSI ID. |
|
|
|
|
|
|
|
The HBAnyware Utility User Manual | Page 90 |
