Table 6: Driver for Linux, LPFC Static Parameters (Requires a driver reload to change) (Continued)











Visible

Variable

Default

Min

Max

Comments

using











sysfs

























lpfc_discovery_threads

32

1

64

Specifies the maximum number of

No









ELS commands that can be











outstanding for a discovery.











Note: The discovery_threads











parameter will default to a value of











64 for private loop topologies











regardless of the configured value.











If there are multiple ports











configured on the host the value of











64 will only be used for those ports











that are connected in a private











loop topology. The configured











value will be used for all other











ports.











Note: On the VMware ESX Server











only, range is 30 - 64. The default











is erroneously set to 1. Set this











parameter to a valid value. If you











do not, when you change any











parameter value, the following











error message may be displayed:











“Driver Parameter ‘discovery-











threads’ is not within the allowed











range”















lpfc_fcp_class

3

2

3

FC class for FCP data

Yes









transmission.















lpfc_link_speed

0

0=auto select

Sets link speed.

Yes





1=1G











2=2G











4=4G











8=8G



















lpfc_hba_queue_depth*

8192

32

8192

Maximum number of FCP

Yes









commands that can queue to an











Emulex HBA.















lpfc_lun_queue_depth

30

1

128

Default max commands sent to a

Yes









single logical unit (disk).















lpfc_topology

0

0x0=loop



FC link topology (defaults to loop,

Yes





then P2P



if it fails attempts point-to-point







0x2=P2P only

mode).







0x4=loop only









0x6=P2P











then loop



















The HBAnyware Utility User Manual

Page 86
