Table 3: LPFC.conf Parameters (Continued)

Property Name	Scope	Default	Min	Max	Dynamic	Comments
auth-cfgparms	Controller	Description and Values: This is the DH-CHAP related driver property for
	Specific	FC-SP support. It is only valid when driver property enable-auth is set to 1.
		This driver property is ignored when enable-auth is set to 0.
		The format of this property is:
		"LWWNRWWNatovamoddirtlisthlistdhgplistraintval"
		LWWN: The WWPN of the local entity, i.e. HBA port. Use the form of
		NNNNNNNNNNNNNNNN, where NNNNNNNNNNNNNNNN is a 16 digit
		representation of the host port World Wide Port Name. Or use
		0000000000000000 to refer to the local port WWPN.
		RWWN: The WWPN of the remote entity, i.e. fabric controller or any remote
		Nport. Use the form of NNNNNNNNNNNNNNNN, where

NNNNNNNNNNNNNNNNis a 16 digit representation of the fabric controller

or Nport FFFFFFFFFFFFFFFF as generic remote fabric port WWPN.

atov: The authentication timeout value in seconds. The atov range is 20 to 999 seconds in hexidecimal. For example, enter 45 seconds as 002d.

amod: The authentication mode. The valid modes are specified as 01 (Disabled), 02 (Enabled) and 03 (Passive). For detailed description of the mode, refer to the Emulex HBAnyware (3.4) utility help page.

dir: The bi-directional authentication parameter. When set to 01, bi- directional authentication is enabled. When set to 00, bi-directional authentication is disabled. When bidirectional authentication is enabled, the key associated with remote entity must be specified in driver property auth- keys.

tlist: The authentication type list. Currently Emulex LPFC driver only supports DH-CHAP, always set tlist to 01000000.

hlist: The authentication hash list. Currently the Emulex LPFC driver only supports MD5 and SHA1. 01 refers to MD5, 02 refers to SHA1. For example: 01020000 means MD5, SHA1 in order of preference. 01000000 means MD5 only.

dhgplist: The DH-CHAP group list in order of preference. Currently Emulex LPFC driver supports NULL DH-CHAP algorithm and non-NULL DH-CHAP algorithm such as DH group 1024, group 1280, group 1536 and group 2048. For example: 0102030405000000 means NULL, group 1024,1280, 1536 and 2048 in order of preference.

raintval: Reauthentication heart beat interval in minutes. For example, 0000012c means the host side will do the reauthentication every 300 minutes. When set to 00000000 then reauthentication heartbeat is disabled.

You can use lpfcX-auth-cfgparms to specify the per HBA instance DH-CHAP authentication parameters setup. Any valid setup in this way will overwrite the auth-cfgparms setup.

The HBAnyware Utility User Manual Page 61
