Fujitsu RX900 S1 15.2.7 Completing the task

306 Maintenance Manual RX900 S1

Cables

Figure 197: Connecting the control panel cable

ÊConnect the control panel cable to the baseboard (1).

ÊClose the cable clamp (2).

15.2.7 Completing the task

ÊPerform the following procedures to complete the task:

1. "Inserting the CPUMEMR in the slot" on page 186

2. "Closing the server" on page 47

3. "Mounting the server in the rack" on page49

4. "Bringing the server back to operation" on page51

5. "Closing the rack door" on page51
