Fill in the Screens

SECTION 1

BEFORE YOU FILL

IN THE SCREENS Now that you have filled in all of your worksheets, you can actually fill in the system screens with the configuration you have chosen. Before you begin to fill in screens, read through this section.

Use the Completed Worksheets

It’s easy to use completed worksheets to configure the system; the worksheets correspond to the voice mail system screens. The screen name is printed in the lower right corner of the worksheet. For those screens with numbered lines, the line numbers on the worksheets correspond to the line numbers on each screen.

This section of the guide walks you through using each worksheet to fill in the system screens, step by step. Sign in to the system, find the screen you want, and answer the worksheet questions in the fields on the screen. Your application can be configured in no time.

If you have any questions as you configure the application, refer to this manual or to the EliteMail VMS/EliteMail Limited Technician Guide for details about system features.

Sign In to the System

Only a System Manager can access and change the system screens. To configure the voice mail system, sign in at the console using a System Manager Personal ID. If you don’t know a System Manager Personal ID, check with the installer.

1.Press . The system prompts: Please enter your ID.

2. Enter a System Manager Personal ID, and press . If asked, enter the System Manager security code, and press . The system displays Application Screen Page 1.

Job Specifications Manual

3 - 1
