FV (Firmware Versions)

FV (Firmware Versions)

Execution:

This command can be executed in the AC POWER ON or DC POWER ON state.

Function:

Displays the version information of the iSPFW and BIOS.

Performs a checksum of the storage area.

Note: The FV command can be executed in Normal mode or

Maintenance mode.

Table 3-32. FV Screen

Screen Image			Reference
iSPyz:---> fv<ENTER>
Firmware Versions	: (currently running firmware is Rxx.xx)
iSP BOOT	(*)	: xx.xx generated on mm/dd/yyyy hh:mm:ss	A
iSP FW bank0		: xx.xx generated on mm/dd/yyyy hh:mm:ss	A
iSP FW bank1	(*)	: xx.xx generated on mm/dd/yyyy hh:mm:ss
BIOS bank	(*)	: xx.xx generated on mm/dd/yyyy hh:mm:ss
Do you want to check the flash memory? (y/[n]) : y<ENTER>			B
checking iSP BOOT bank...
passed.
checking iSP FW bank0...
passed.			C
checking iSP FW bank1...			C
passed.
checking BIOS bank...
passed.
FV command terminated.

Table 3-33 FV Screen References

Reference Description

ADisplays the state of the current FW storage area.

BTo perform a checksum test of the storage area, enter “y”.

CDisplays the state of the checksum test.

Service Processor 3-31

Image 81
