Main Chassis

This appendix provides the technical specifications for your server.

Main Chassis

Table A-1 lists the technical specifications for the Main Chassis.

Table A-1. Main Chassis Technical Specifications

Item	Specification

CELLV Board

Number of CELLV Boards	Up to 2 boards (one board required)

CPU	Intel® Itanium® 2 1.5-GHz or 1.3-GHz processor
Number of Processors	Up to 4 processors per CELLV board, 8 processors per system

Cache	L1 — Instruction 16KB + Data 16KB
	L2 — 256 KB
	L3 — 6 MB/1.5GHz processor; 3 MB/1.3-GHz processor

Main Memory	Type — 1-GB DDR DIMM
	Number of DIMM Slots — 16 per CELLV Board
	Expansion — 4-GB; installed in units of 4 DIMMs
	Minimum Memory — 4 GB
	Maximum Memory — 16 GB per CELLV Board, 32 GB per system using
	1-GB DIMMs

I/O Processing	Interface — one 1.6-GB Interface in Core Module

	Maximum Number of PCI Slots
	12 slots in Core Module
	14 slots in Base PCIX Unit
	(26 slots in system)

	Maximum I/O Bandwidth — 6.4GB/s per CELLV Board

	Core Module Slots
	8 slots supporting 66-MHz PCI bus
	4 slots supporting 133-MHz PCI bus

	Base PCIX Unit Slots
	8 slots supporting 66-MHz PCI bus
	6 slots supporting 133-MHz PCI bus

Interconnection between CELLV Boards

Method — Crossbar switch

Max. Operating Frequency — 400MHz

Max. Bandwidth — 25.6GB/s

A-2 Technical Specifications

Image 194
