SCSI Hard Disk Drives

	Recommended Settings or			Your Configuration

		0	1		2	3	4	5
Descriptions	Display Only	0	1		2	3	4	5
Descriptions	Display Only

Device Selections	Press Enter for menu. Select
	device and press Enter.

Sync Rate	40

Width (bits)	16

Disconnect	On

Read/Write I/O	10
timeout (sec)

Scan for device at	Yes
boot time

Scan for SCSI	No
LUNS

Queue Tags	On

		SCSI Removable Media Devices

		Recommended Settings or	Your Configuration

			Dev 0	Dev 1	Dev 2	Dev 3
	Descriptions	Display Only	Dev 0	Dev 1	Dev 2	Dev 3
	Descriptions	Display Only

	Device Selections	Press Enter for menu. Select
		device and press Enter.
	Sync Rate	10
	Width (bits)	8
	Disconnect	On
	Read/Write I/O	10
	timeout (sec)
	Scan for device at	Yes
	boot time
	Scan for SCSI	No
	LUNS
	Queue Tags	On

3.Highlight the function you want to change and press Enter. You are prompted to save changes when you exit the configuration utility.

Note: If you wish to format a disk or verify disk media, select “Format” or “Verify” from the Device Setup menu.

Configuring Your System 3-19
