RSG Configuration Script Menu

The RSG Configuration Script Menu is used to manage the download of configuration script files for the transceiver.

RSG Configuration Scripts Menu

A) RSG Config Host Address

169.254.0.1

B) RSG Config Filename

rsgcfg.txt

C) TFTP Timeout

30 sec

D)Send File

E)Retrieve File

Select a letter to configure an item, <ESC> for the prev menu

RSG Config Host Address—This is the IP address of the host computer. This computer also runs a TFTP server to transmit or receive configuration files.

RSG Config Filename—The name of the file that has been created or uploaded from an existing AP. This file contains all of the programmable parameters of the transceiver.

TFTPTimeout—This field shows the amount of time that the radio receiving information waits before reporting a fault condition.

Send File—Sends the onboard configuration file to a remote host device.

Retrieve File—This command initiates the download of the configuration file from the TFTP server PC.

3-54 TranSphere TS Wireless Extended Range IP Networking Transceivers – January 2008 GFK-2489
