Epson L90 Interface And Connectors

Rev. B Interface And Connectors A-1

TM-L90/TM-L90 with Peeler Technical Reference Guide

Appendix A

Interface And Connectors

A.1 RS-232 Serial Interface

A.1.1 Interface board specifications (RS-232 standard)

Item Specifications

Data transfer

method

Serial

Synchronization Asynchronous

Handshake Select one of the following using DIP switch 3 or the memory switches (switch

operation/command (operation).

❏DTR/DSR

❏XON/XOFF

Signal level MARK -3 V to -15 V logic "1" /On

SPACE +3 V to +15 V logic "0" /Off

Bit length Select one of the following using DIP switch 4 or the memory switches (switch

operation/command (operation).

❏7 bit

❏8 bit

Baud rate Select one of the following using DIP switches 7/8 or the memory switches (switch

operation/command (operation).

❏115200 bps (can be set only using the memory switches)

❏57600 bps (can be set only using the memory switches)

❏38400 bps (can be set only using the memory switches)

❏19200 bps

❏9600 bps

❏4800 bps

❏2400 bps

[bps: bits per second]

Parity check Select one of the following using DIP switch 5 or the memory switches (switch

operation/command (operation).

❏Yes

❏No

Parity selection Select one of the following using DIP switch 6 or the memory switches (switch

operation/command (operation).

❏Even

❏Odd

Stop bit 1 or more bits

However, the stop bit of the transfer data from the printer is fixed at 1 bit.

Connector Printer

side

Dsub-25pin (female) connector
