Epson L90 Rev. B

Rev. B Troubleshooting F-7

TM-L90/TM-L90 with Peeler Technical Reference Guide

❏TM-L90 peeler specification unrecoverable errors

Note:

When an unrecoverable error occurs, turn off the power supply immediately.

Unplug the power cablefrom the printer body when the power switch is invalid.

Unrecoverable Errors

Error name Type of error Error LED Flash code Recovery measure

R/W error in memory After R/W checking, the

printer does not work

correctly.

Impossible to

recover.

High voltage error The power supply voltage is

extremely high.

Impossible to

recover.

Low voltage error The power supply voltage is

extremely low.

Impossible to

recover.

CPU execution error The CPU executes an

incorrect address or I/F

board is not connected.

Impossible to

recover.

Internal circuit

connection error

Internal circuits are not

connected correctly.

Impossible to

recover.

UIB error An abnormal operation

occurs in UIB.

Impossible to

recover.

Approx.320 ms

Approx.5120 ms

Approx.2560 ms
