Unrecoverable errors

Normal printer operation is no longer possible when unrecoverable errors occur. The printer may be out of order. Contact the store for repair.

❏TM-L90 unrecoverable errors

Unrecoverable Errors

Error name

Type of error

Error LED

Flash code

Recovery measure

Approx.320 ms

R/W error in memory

After R/W checking, the

Impossible to

printer does not work

recover.

correctly.

Approx.5120 ms

High voltage error

The power supply voltage is

Impossible to

extremely high.

recover.

Low voltage error

The power supply voltage is

Impossible to

extremely low.

recover.

CPU execution error

The CPU executes an

Impossible to

incorrect address or I/F

recover.

board is not connected.

Internal circuit

Internal circuits are not

Impossible to

connection error

connected correctly.

recover.

Approx.2560 ms

UIB error

An abnormal operation

Impossible to

occurs in UIB.

recover.

F-6Troubleshooting

Rev. B

Image 184
