Maintaining PCI cards

9.Insert the PCI card into the slot on the I/O board. Make sure that the card is fully seated. See the following figure.

When the card is inserted, the amber OK-to-Remove LED lights and a message similar to the following is displayed on the console window:

Jun 6 12:55:24 sys_name picld[98]: Device PCI1_CARD inserted

10.Rotate the purple PCI retaining clip over the back of the card faceplate until it snaps into place.

11.Press the hot-plug button for the card you are installing. After the button is pressed, the following should occur:

●The amber Fault LED for the slot may blink briefly and then turn off.

●The green Power LED lights.

●A message similar to the following is displayed on the console window:

Jun 6 12:57:11 sys_name pcihp: NOTICE: pcihp (pcisch0): card is powered on in the slot hpc1_slotX

! Important:

If the Fault LED remains off or stays lit after inserting a card, you must shut down the system, reinsert the card, and reboot the system.
