Baldor E100 6.1 Introduction

www.supportme.net

Configuration 6-1MN1942

6.1 Introduction

Beforepowering the MicroFlex e100 youwill need to c onnect it to the PC using aUSB or Ethernet

cableand install the s upplied MintMac hine Center software. This softwar e includes a number of

tools to allow you to configure and tune the MicroFlex e100. If you do not have experience of

software installation or Windows applications you may need further assistance for this s tage of

theinstallation.

6.1.1 Con necting the MicroFlex e100 to the PC

TheMicroF lex e100 can be connected to the PC using either USB or TCP/I P.

Touse USB, connect a U SB cable between a PC USB port and the MicroFlex e100 USB port.

YourPC must be using Windows 2000 or Windows XP.

Touse TCP/IP, connect a CAT5 Ethernet cable between the PC and one of the MicroFlex e100

Ethernetpor ts.

CAUTION: Youcannot connect an ordinary office PC to the Mic roFlex e100 without first

altering the PC’s Ethernet adapter configuration. However, if you have

installed a second Ethernet adapter dedicated for use with the

MicroFlex e100, then this adapter’s configuration can be altered without

affecting the PC’s office Ethernet connection. If y ou are unsure about

making changes to your PC’s Ethernet adapter c onfiguration, or are

prevented by user permission levels, ask your I.T. administrator to assist

you.

CAUTION: Ifthere is a EPL manager node (node I D 240) on the Ethernet network , then

the network will be operating in EPL mode. This means any TCP/IP

connection from the PC must pass through an EPL compatible router.

6.1.2 Installing Mint Machine Center and Mint WorkBench

Youwill need to install Mint Machine Center ( MMC) and Mint WorkBench to configure and tune

the MicroFlex e100. Any previous version of Mint WorkBench must be unins talled before

proceedingw ith this installation:

1. Insertthe CD int o the drive.

2. Aftera few seconds the setup w izard should start automatically. If the setup wizard does not

appear,select Run... from the Windows Start menu and type

d:\start

wheredrepr esents the drive letter of the CD device.

Follow the on-screen instructions to install MMC (including Mint WorkBenc h). Thes etup

wizard will copy the files to appropriate folder s within the C:\Program Files folder, and place

shortcuts on the Windows Start menu.

6Configuration 6
