4Remove the white plug from the port labeled
5If your PC modem software is set to receive faxes to your computer automatically, turn off that setting.
Caution If you do not turn off the auto fax receive setting in your PC modem software, your HP
6(Optional) Connect a phone to the other open phone port on the parallel splitter.
7Set up the HP
8Run a fax test. For information, see Test your fax setup.
You must be available to respond in person to incoming fax calls, or your HP
Set up your HP all-in-one to a computer with two phone ports
Back view of the HP all-in-one
1 Telephone wall jack
2 "IN" phone port on your computer
3 "OUT" phone port on your computer
4 Telephone
5 Computer with modem
6 Phone cord supplied in the box with your HP
To set up your HP
1Remove the white plug from the port labeled
2Find the phone cord that connects from the back of your computer (your PC modem) to a telephone wall jack. Disconnect the cord from the telephone wall jack and plug it into the port labeled
3Connect a phone to the "OUT" port on the back of your PC modem.
Fax setup
User Guide | 73 |
