Chapter 4 Command Reference

Measurement Instructions (:CONFigure, :FETCh, :MEASure, :READ)

	Measurement Instructions (:CONFigure,
	:FETCh, :MEASure, :READ)
	The purpose of these commands is to acquire data using a set of high-level
	instructions. These commands are structured to allow you to trade off
	interchangeability with fine control of the measurement process. The :MEASure
	query provides a complete capability where the instrument is configured, a
	measurement is taken, and the results are stored in the Output Queue in one
	operation.
	When more precise control of the measurement is required,
	the :CONFigure and :READ? commands can be used. :CONFigure performs the
	configuration portion of the measurement.
	:READ? performs the data acquisition and post processing (if any), and then it
	places the results in the Output Queue. This allows generic configuration of the
	instrument using :CONFigure, and then customization of the measurement with
	other commands
	(for example, from the [:SENSe] subsystem). :READ? completes the measurement
	process.
	The :READ? command, in turn, is composed of the :INITiate[:IMMediate] and
	:FETCh? commands. :INITiate[:IMMediate] performs the data acquisition. :FETCh?
	performs the post-processing function (if any) and places the result in the Output
	Queue. This allows more than one FETCh? on a single set of acquired data.

	Summary of the Measurement Instruction Commands

:MEASure query	This command is the simplest to use, but allows few additional possibilities. This
	command lets the Counter configure itself for an optimal measurement, initiate
	measurement, and return the result; that is, it provides complete measurement sequence
	(:MEAS query is equivalent to the :CONF, :INIT, :FETC? command sequence, but with
	no flexibility.)

:CONFigure	The combined use of these two commands allows for more control when the Counter
:READ?	performs measurement, initiates measurement, and returns the result. Use this command
	sequence if you are planning for the Counter to perform something in between the
	measurement setup and acquisition.

:CONFigure	This combination of commands allows for the most flexibility . This command sequence
:INITiate	configures the Counter, initiates the measurement as specified, and returns the result.
:FETCh?

4-52	Programming Guide
