Chapter 7 - Options

5) LED Indicator lamp description

DBU has three LED indicator lamps.

	Display			Description
	POWER			Power LED turns Red when input power is applied to DBU.
	RUN			RUN LED is blinking while the DBU is activated by motor regenerating energy.
	OHT			The unit shuts down the output and turns OHT LED ON when the heatsink is overheated
	OHT			in operation by its protection function.
				in operation by its protection function.

OHT POWER RUN

▶POWER LED (Red) : indicates input power is applied.

▶RUN LED (Green) : indicates Dynamic braking is active.

▶OHT LED (Green) : indicates Over Heat Trip occurs
