206 | Dell PP12S instruction

A U D I O C O N N E C T O R

Connect headphones or speakers. The connector is a stereo output connector.

IEEE 1394 C O N N E C T O R

Connect FireWire devices such as a camera, external hard drive, or external CD-ROM drive. Supports hot swapping, multiple speeds on the same bus, and time-based data transfer, providing bandwidth for multimedia operation.

VGA V I D E O C O N N E C T O R

Connects an external VGA monitor.

NOTE: When your Tablet-PC is docked, use the video connector on the media base.

D I G I T A L - V I D E O I N T E R F A C E (DVI) C O N N E C T O R

Connects an external DVI-compatible monitor, such as a flat-panel monitor. With an adapter cable, you can also connect an external VGA-compatible monitor to the DVI connector.

Media Base (Optional)
