User Information

$ telnet brown

Trying 154.12.26.6 ...

Connected to 154.12.26.6

Character mode is enabled.

Escape character is '^]'.

Notice from LCS60(brown)...

The following editing characters are valid during input at prompts:

--An ASCII "backspace" erases the last character typed,

--An ASCII "@" deletes the entire input line.

brown LCS60 DESTINATION:

- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -

$ telnet brown 2222

Trying 154.12.26.6 (Port 2222)...

Connected to brown.lab.att.com

Character mode is enabled.

Escape character is '^]'.

Notice from LCS60(brown)...

--Connected to Data Switch Address: mlkway/earth/watson login:

Gateway

UUCP Feature

Data Switch to LCS60 to LAN

To transfer files using uucp between a host attached to a CommKit Host Interface and an Ethernet host on the LCS60, the /usr/lib/uucp/Systems file must be modified on the host that is connected to the CommKit Host Interface.

The host originating the uucp connection must be attached to the CommKit Host Interface. For Ethernet-connected hosts that cannot initiate uucp connections to CommKit Host Interface connected hosts by means of the LCS60, configure CommKit Host Interface connected hosts to regularly poll Ethernet-connected hosts for uucp traffic.

There are two ways to set up the uucp feature for data switch to LCS60 to LAN file transfer:

Issue 3

7-13
