lcsadm Interface

Name show

Synopsis show

Description The show command gives information about the LCS60, including details such as process ID, start time, location of log files, log levels, and number of software servers.

Name update

Synopsis update

Description The update command resets the LCS60 manager configuration.

In addition to the main directories (Top, Service, Ports, Session, and Config), a Server directory (Screen 8-6) is available from the Manager directory.

Note: The Server directory is a diagnostic tool for checking protocol service information and is not intended for normal administrative purposes.

Screen 8-6: Server Directory

Top>Manager># server

Top>Manager>Server># Return

Commands may be abbreviated. Commands are:

config/	help	log	manager/	ports/
quit	service/	session/	show	top/
types	^	!

Administration

The following commands are available from the Server directory:

Name log

Synopsis

log service-type level

Issue 3

8-15
