HP LCS60 Note:, Notes:, Figure F-7:IP Address Screen

PPP Service Examples

Notes: US Robotics Sportster in the preceding figure is the dialing script (CCL) which contains the necessary instructions to set up the modem and log on to the LCS60. Modem Port selects which device the modem is connected to; the modem port is usually designated. When setting your physical link parameters (LCP) you can take the defaults as shown on the right. Make sure PAP/CHAP authentication are not selected. Authentication is handled by the NAC.

Figure F-7: IP Address Screen

Note: If you are using a privately administered IP address, enter it in the Local IP Address field on the screen above, otherwise the LCS60 will dynamically assign an IP address (when a negotiable IP address has been administered in the client software package).

Information User

Issue 3

F-17
